Motor data:
| Voltage Range | Max Power | Max Current | Max Depth | No-load speed | Max Thrust | Weight |
| 8-16V | 60W | 8A | 150m | 6000-15000rpm | 0.8kgf | 38g |
| 8-16V | 80W | 10A | 150m | 6000-15000rpm | 1kgf | 45g |
| 8-16V | 100W | 12.5A | 200m | 5000-12000rpm | 1.4kgf | 53g |
| 12-24V | 120W | 12.5A | 200m | 5000-12000rpm | 1.6kgf | 67g |
| 12-24V | 160W | 12.5A | 200m | 5000-11000rpm | 2kgf | 85g |
| 16-32V | 300W | 12.5A | 300m | 3000-9000rpm | 3.5kgf | 138g |
| 24-48V | 600W | 25A | 500m | 3000-6500rpm | 6kgf | 315g |
| 24-48V | 650W | 27A | 500m | 3000-6500rpm | 6.5kgf | 310g |
Gearbox data:
All above parameters including voltage, current, power, torque, install dimension, shaft shape and size, can customized according to your rerquirement.
Application:
Vending machine, home appliance, engraving machine, cutting plotter, textile machine, CNC machine, 3D printer, car, UAV and other industrial automatic equipment, toys, electrical tools, office equipment, bank equipments,payment equipments,power door lock,electric door lock, window opener.
