Motor data:
| Voltage Range | No-load | On-load | Stall | |||||
| Current | Speed | Current | Speed | Torque | Output power | Torque | Current | |
| mA | RPM | mA | RPM | gf.cm | W | gf.cm | mA | |
| 6V | ≤40 | 3000 | ≤160 | 2500 | 15 | 0.4 | ≥68 | ≥520 |
| 6V | ≤56 | 4500 | ≤300 | 3300 | 25 | 0.8 | ≥115 | ≥860 |
| 6V | ≤80 | 6000 | ≤450 | 4500 | 35 | 1.6 | ≥165 | ≥1800 |
| 12V | ≤20 | 3000 | ≤80 | 2500 | 15 | 0.4 | ≥68 | ≥250 |
| 12V | ≤35 | 4500 | ≤150 | 3300 | 25 | 0.8 | ≥115 | ≥560 |
| 12V | ≤50 | 6000 | ≤220 | 4500 | 35 | 1.6 | ≥165 | ≥980 |
Gearbox data:
| Number of stages | 3 | 4 | ||||||
| Reduction ratio | 71, 109, 127, 153, 174, 190 | 244, 263, 285, 309, 336, 367, 539, 603, 684, 742, 806, 865, 1217, 1336, 1474 | ||||||
| Gearbox length L mm | 25 | 25 | ||||||
| Breaking torque(kgf.cm) | 10 | 15 | ||||||
| Gearbox efficiency | 40% | 36% |
Application:
Game machine, Vending machine, home appliance, engraving machine, cutting plotter, textile machine, CNC machine, 3D printer, car, UAV and other industrial automatic equipment, toys, electrical tools, office equipment, bank equipments,payment equipments,power door lock,electric door lock, window opener.
